Drip line with Flat Dripper
Lin Driplines – Non-compensated dripper
Lin is a flat, integral, non-compensated dripper that has become the industry standard in its category, reflecting reliability and efficiency. The Lin dripline is the ideal choice for farmers seeking an affordable irrigation solution lasting 2–3 seasons. Its wide inlet filter prevents clogging, ensuring continuous irrigation even in challenging water conditions.
Technical data:
Dripline diameters | 12/16/17/20/22 mm
Dripline wall thickness | 0.15/0.2/0.3/0.4/0.6/0.9/1.0 mm
Drippers spacing | 10/20/30/40/50/70/100/other cm
Ddripper’s waterflow | 0.8/1.2/1.6/2/3/4/6 L/hr
Applications: Open field | Orchards | Greenhouses |Landscaping
Features
- High clogging resistance due to wide water passages along the primary labyrinth
- Short and wide self-cleaning labyrinth with turbulent flow to prevent particle settling
- Highly resistant to UV exposure and common agricultural fertilizers
- Very low CV (Coefficient of Variation) for consistent performance
Higlights
- Available diameters: 12mm, 16mm, 17mm, 20mm, 22mm and 25mm
- Precisely welded into low/medium wall driplines with thicknesses ranging from 0.20mm to 0.9mm.
- Optional Rootguard Band® extruded layer to prevent root intrusion in SDI applications.
- Optional Cleanline® extruded layer to prevent clogging when using water with high organic content.
Calculate Lin driplines running length
Calculate your irrigation system with Irrimetzer App
